Apache Cassandra Lab Environment

Production-grade multi-datacenter Apache Cassandra cluster deployment on Hetzner Cloud with AxonOps monitoring. This project combines Terraform for infrastructure provisioning and Ansible for automated configuration management.

Overview

This lab environment provides:

Multi-datacenter Cassandra cluster with configurable node count (currently 12 nodes)
Infrastructure as Code using Terraform for Hetzner Cloud
Configuration Management using Ansible with AxonOps collection
Production features: SSL/TLS encryption, authentication, audit logging, monitoring
Web-based terminal access via Wetty for easy cluster management
Comprehensive monitoring with AxonOps SaaS platform

Architecture

Current Default Topology (12 Nodes)

┌─────────────────────────────────────────────────────────────┐
│              Hetzner Cloud Infrastructure                   │
│                                                             │
│  ┌──────────────────────────────────────────────────────┐   │
│  │  Private Network (10.18.0.0/16)                      │   │
│  │                                                      │   │
│  │  Datacenter dc1          Datacenter dc2              │   │
│  │  ┌──────────┐             ┌──────────┐               │   │
│  │  │ rack1 (2)│             │ rack1 (2)│               │   │
│  │  │ rack2 (2)│             │ rack2 (2)│               │   │
│  │  │ rack3 (2)│             │ rack3 (2)│               │   │
│  │  └──────────┘             └──────────┘               │   │
│  │  6 nodes                  6 nodes                    │   │
│  └──────────────────────────────────────────────────────┘   │
│                                                             │
│  ┌──────────────┐                                           │
│  │   Bastion    │ (SSH + Web Terminal)                      │
│  └──────────────┘                                           │
└─────────────────────────────────────────────────────────────┘

Key Features:

2 datacenters (dc1, dc2) for multi-DC replication
3 racks per datacenter for rack-aware topology
Placement groups ensure physical host diversity
GossipingPropertyFileSnitch for datacenter/rack awareness
4 seed nodes (2 per DC) for reliable cluster formation
Private networking (10.18.0.0/16) for inter-node communication

Prerequisites

Required Accounts & Credentials

Hetzner Cloud
- You'll need a Hetzner Cloud account with API token
- The token requires read/write permissions
- Set via environment variable: export HCLOUD_TOKEN="your-token"
AxonOps Free Account

AxonOps provides a free tier for monitoring Cassandra clusters. To sign up:

Step 1: Create Account
- Visit AxonOps
- Click "Sign Up" or "Free Account"
- Provide your email, name, and create a password
- Verify your email address
Step 2: Create Organization
- After logging in, you'll be prompted to create an organization
- Choose a unique organization name (e.g., "my-company")
- Note: This organization name is used in configuration files
Step 3: Get Agent Key
- Navigate to https://console.axonops.cloud/
- Use the left menu to select the Agent Setup
- Copy your agent key
Step 4: Get API Token (for alerts)
- Navigate to API Tokens
- Click "Create a New Token"
- Copy the token immediately (it's only shown once)
- This token is used to configure alerts via Ansible

Required Tools

Tool	Version	Purpose
Terraform	>= 1.0	Infrastructure provisioning
Ansible	>= 2.9	Configuration management
Pipenv	Latest	Python dependency management
SSH	Any	Server access

Python Environment Management

📦 Python Dependency Management: This project uses Pipenv by default to manage Ansible and Python dependencies in an isolated virtual environment. This ensures consistent versions across all team members and prevents conflicts with system packages.

Using Pipenv (Recommended):

# Install dependencies (done automatically by Makefile)
cd ansible
pipenv install

# All make commands use pipenv automatically
make prep
make cassandra ENVIRONMENT=lab ANSIBLE_USER=root

Using System Python or venv (Alternative):

If you prefer to use your system Python installation or manage your own virtual environment, you can disable Pipenv:

# Disable Pipenv for the current session
export PIPENVCMD=""
export PIPENV=false

# Then use make commands as normal
cd ansible
make prep

When to disable Pipenv:

CI/CD pipelines with pre-configured Python environments
Container-based deployments with dependencies pre-installed
System-wide Ansible installations in production automation servers
Custom virtual environment management with venv or conda

💡 Tip: If you disable Pipenv, ensure you manually install the required Python packages:
pip install -r ansible/requirements.txt

Install Dependencies

# macOS
brew install terraform ansible pipenv

# Ubuntu/Debian
sudo apt-get install terraform ansible pipenv

# Fedora/RHEL
sudo dnf install terraform ansible pipenv

Quick Start

1. Clone and Setup

git clone <repository-url>
cd ansible-cassandra-lab

2. Configure Environment Variables

# Hetzner Cloud API token
export HCLOUD_TOKEN="your-hetzner-cloud-api-token"

# AxonOps credentials (for alerts configuration)
export AXONOPS_ORG="your-organization-name"
export AXONOPS_TOKEN="your-api-token"

# Ansible vault password (create this file)
export ENVIRONMENT=lab
export ANSIBLE_VAULT_PASSWORD_FILE=~/.ansible_vault_pass_${ENVIRONMENT}
echo "your-secure-vault-password" > ~/.ansible_vault_pass_${ENVIRONMENT}
chmod 600 ~/.ansible_vault_pass_${ENVIRONMENT}

3. Provision Infrastructure with Terraform

⚠️ STATE BACKEND WARNING: This environment uses local Terraform state files which are only suitable for lab environments. For staging and production environments, you MUST configure a remote state backend (S3, Azure Storage, Terraform Cloud, etc.) to ensure state consistency and enable team collaboration.

☁️ CLOUD PROVIDER NOTE: This lab environment uses Hetzner Cloud. With minimal effort, the Terraform code can be adapted to create infrastructure on any other cloud provider (AWS, Azure, GCP) or even on-premises. The Ansible playbooks will remain the same regardless of where the infrastructure is provisioned.

SSH Key Configuration

🔑 SSH Key Management: Terraform can either use existing SSH keys from your Hetzner Cloud account or automatically generate new ones. Choose the approach that fits your workflow.

Option 1: Use Existing Hetzner SSH Keys (Recommended for Teams)

If you already have SSH keys configured in your Hetzner Cloud project:

# In terraform/terraform.tfvars
ssh_keys = ["my-ssh-key"]  # Name of your existing Hetzner SSH key

Benefits:

✅ Use your existing SSH keys
✅ Keys are managed centrally in Hetzner
✅ Multiple team members can use the same key
✅ No local key files to manage

Option 2: Auto-Generate SSH Keys (Default - Easy for Lab)

If you don't specify SSH keys, Terraform will automatically generate a new key pair:

# In terraform/terraform.tfvars
ssh_keys = []  # Empty array = auto-generate keys

What happens:

New SSH key pair generated in terraform/ssh_key (private) and terraform/ssh_key.pub (public)
Private key has permissions automatically set to 600
Key is uploaded to your Hetzner project
All infrastructure uses this key

Using the Auto-Generated Key:

After Terraform creates the infrastructure, you need to use the generated key for SSH access:

# Option A: Add to ssh-agent (recommended - works automatically)
eval $(ssh-agent)
ssh-add terraform/ssh_key

# Verify it's loaded
ssh-add -l

# Now SSH works without specifying the key
ssh root@<node-ip>

# Option B: Specify key with each SSH command
ssh -i terraform/ssh_key root@<bastion-ip>
ssh -i terraform/ssh_key root@<node-ip>

⚠️ IMPORTANT: Do NOT commit terraform/ssh_key (private key) to Git. The .gitignore file excludes it by default.

Comparison:

Aspect	Existing Keys	Auto-Generated Keys
Setup	Configure in Hetzner first	Automatic
Team Use	✅ Multiple users	❌ Single user
Management	Centralized	Local file
Best For	Production, Teams	Lab, Solo development

cd terraform

# Initialize Terraform
make tf-init

# Review what will be created
make tf-plan

# Create infrastructure (12 nodes + bastion)
make tf-apply

📋 IMPORTANT - Ansible Inventory Management: Terraform automatically generates the Ansible inventory at ansible/inventories/lab/hosts.ini based on your infrastructure. This file contains all node IPs, datacenter/rack assignments, and seed node configuration.

You should commit this inventory file to Git because:

Ansible requires it for all subsequent deployments and configuration changes

It defines your cluster topology (datacenters, racks, seed nodes)

It only changes when you scale the cluster (add/remove nodes)

Other team members need it to work with the same cluster

After scaling your cluster, run make tf-inventory-save and commit the updated inventory file.

4. Configure Secrets with Ansible Vault

cd ../ansible

# Edit the vault file with your AxonOps credentials
ansible-vault edit group_vars/lab/vault.yml

Add the following content:

vault_axon_agent_customer_name: "example"
vault_axon_agent_key: 248d6d04144de3f0xxxxxx # get this from https://console.axonops.cloud/

vault_cassandra_ssl_internode_keystore_pass: changeit
vault_cassandra_ssl_keystore_pass: changeit
vault_cassandra_ssl_client_keystore_pass: changeit
vault_cassandra_ssl_client_truststore_pass: changeit

5. SSL/TLS Certificate Configuration

🔒 SECURITY BEST PRACTICE: Apache Cassandra should always be configured with encryption (node-to-node and client-to-node) for production deployments.

The Ansible playbook supports two SSL certificate management approaches:

Option A: Auto-generated Certificates (Lab/Development Only)

For lab environments, Ansible can automatically generate self-signed certificates:

# In group_vars/lab/cassandra.yml
cassandra_ssl_create: true

What happens:

Ansible generates unique SSL certificates for each Cassandra node
Certificates are stored locally in ansible/files/ssl/<env>/
Keystores and truststores are created automatically

Important:

✅ Commit these files to Git - They're needed for consistent cluster operation
⚠️ Lab environments ONLY - Self-signed certificates are not suitable for production
📁 Files are stored unencrypted in the repository for convenience

Option B: Managed Certificates (Staging/Production - Recommended)

For production and staging environments, use properly managed certificates:

# In group_vars/prd/cassandra.yml
cassandra_ssl_create: false  # Disable auto-generation

Production certificate management:

Generate certificates using your organization's PKI/CA infrastructure
Store certificates securely using:
- Ansible Vault encrypted files (ansible-vault encrypt_string)
- External secret management (HashiCorp Vault, AWS Secrets Manager, Azure Key Vault)
- Encrypted storage with restricted access
Place certificates in ansible/files/ssl/<env>/ (encrypted)
DO NOT commit unencrypted production certificates to Git

You can find more information in the Ansible Role documentation.

Example production setup:

# Store passwords in vault
ansible-vault edit group_vars/prd/ssl_vault.yml

💡 Tip: For production, consider certificate rotation policies and use certificates from a trusted CA rather than self-signed certificates.

6. Deploy Cassandra Cluster

# Install Ansible dependencies
make prep

# Apply base system configuration (OS hardening, NTP, etc.)
make common ENVIRONMENT=lab

# Deploy Cassandra and AxonOps agent
make cassandra ENVIRONMENT=lab

# Configure AxonOps monitoring and alerts
make alerts ENVIRONMENT=lab

7. Access Your Cluster

NOTE: It is highly recommended or even necessary to set up ssh-agent to be able to SSH from the bastion to the cassandra nodes. You can read me here.

# Get Bastion IP
grep bastion ansible/inventory/${ENVIRONMENT}/*

# Access web terminal
https://<bastion-ip>/wetty
# Username: (configured in group_vars/all/wetty.yml)
# Password: (set in group_vars/<env>/vault.yml as vault_wetty_http_password)

# From bastion, connect to any Cassandra node See note about ssh-agent above ⬆️
ssh root@<node-private-ip>

# Check cluster status
nodetool status

8. Connect with AxonOps Workbench

AxonOps Workbench is a desktop application for connecting to and querying Cassandra clusters. This project includes a pre-configured workspace for easy access.

Download and Install:

Visit axonops.com/workbench to download the desktop application
Available for Windows, macOS, and Linux

Import the Workspace:

Open AxonOps Workbench
Navigate to File → Import Workspace
Select the workbench/Training Workspace directory from this repository
Enter your Cassandra credentials when prompted (credentials will be provided to you)
Connect and start querying your cluster

See the workbench/README.md for detailed instructions.

Project Structure

ansible-cassandra-lab/
├── README.md                       # This file
├── .gitignore                      # Git ignore patterns
│
├── terraform/                      # Infrastructure as Code
│   ├── main.tf                    # Main infrastructure (12 nodes + bastion)
│   ├── variables.tf               # Configurable parameters
│   ├── outputs.tf                 # Inventory generation & outputs
│   ├── providers.tf               # Hetzner Cloud & MinIO providers
│   ├── bucket.tf                  # Object storage configuration (optional)
│   ├── terraform.tfvars.example   # Configuration template
│   ├── README.md                  # Terraform-specific documentation
│   └── *.tfvars                   # Environment-specific configs
│
└── ansible/                       # Configuration Management
    ├── Makefile                   # Main entry point - run all commands from here
    ├── ansible.cfg                # Ansible configuration
    ├── Pipfile                    # Python dependencies
    ├── requirements.yml           # Ansible Galaxy collections & roles
    ├── LICENSE                    # Project license
    │
    ├── Playbooks (root level):
    │   ├── common.yml            # OS hardening, NTP, base packages, Wetty
    │   ├── cassandra.yml         # Java, Cassandra 5.0.5, AxonOps agent
    │   ├── alerts.yml            # AxonOps monitoring configuration
    │   ├── rolling-restart.yml   # Safe sequential cluster restart
    │   ├── wipe.yml              # Stop services & wipe data (destructive)
    │   ├── _keystore.yml         # SSL keystore generation (imported)
    │   └── _wetty.yml            # Web terminal setup (imported)
    │
    ├── inventories/              # Terraform auto-generates these
    │   ├── lab/
    │   │   └── hosts.ini         # Lab environment inventory
    │   ├── stg/
    │   │   └── hosts.ini         # Staging environment inventory
    │   └── prd/
    │       └── hosts.ini         # Production environment inventory
    │
    ├── group_vars/
    │   ├── all/                  # Global defaults for all environments
    │   │   ├── common.yml       # Common variables
    │   │   ├── cassandra.yml    # Cassandra 5.0.5 default settings
    │   │   └── axonops.yml      # AxonOps agent 2.0.9 default config
    │   │
    │   ├── lab/                 # Lab environment overrides
    │   │   ├── cassandra.yml    # Lab-specific performance tuning
    │   │   ├── axonops.yml      # Lab organization settings
    │   │   ├── ssl.yml          # SSL/TLS configuration (optional)
    │   │   ├── vault.yml        # Encrypted credentials
    │   │   └── ssl_vault.yml    # Encrypted SSL passwords
    │   │
    │   ├── stg/                 # Staging environment overrides
    │   │   ├── cassandra.yml
    │   │   ├── axonops.yml
    │   │   └── vault.yml        # Encrypted
    │   │
    │   └── prd/                 # Production environment overrides
    │       ├── cassandra.yml
    │       ├── axonops.yml
    │       ├── ssl.yml
    │       ├── vault.yml        # Encrypted
    │       └── ssl_vault.yml    # Encrypted
    │
    ├── alerts-config/            # AxonOps monitoring (YAML-driven)
    │   └── <org-name>/          # Your organization name (e.g., "training")
    │       │
    │       ├── Organization-level configs:
    │       │   ├── alert_endpoints.yml     # Integrations (Slack, PagerDuty, email)
    │       │   ├── metric_alert_rules.yml  # Default metric alerts (all clusters)
    │       │   └── log_alert_rules.yml     # Default log alerts (all clusters)
    │       │
    │       ├── lab/              # Lab cluster monitoring
    │       │   ├── alert_routes.yml         # Route alerts to endpoints
    │       │   ├── backups.yml              # Backup schedules & retention
    │       │   ├── service_checks.yml       # Custom health checks
    │       │   ├── commitlog_archive.yml    # Commitlog archiving config
    │       │   ├── dashboards.yml           # Custom dashboard definitions
    │       │   ├── metric_alert_rules.yml   # Cluster-specific metric alerts
    │       │   └── log_alert_rules.yml      # Cluster-specific log alerts
    │       │
    │       ├── stg/              # Staging cluster monitoring (same structure)
    │       │   └── ...
    │       │
    │       └── prd/              # Production cluster monitoring (same structure)
    │           └── ...
    │
    ├── templates/
    │   └── alerts/               # Jinja2 templates for service check scripts
    │       ├── check-node-down.sh.j2
    │       ├── check-keyspaces-strategy.sh.j2
    │       └── check-schema-disagreements.sh.j2
    │
    ├── files/
    │   └── ssl/                  # SSL certificates per environment
    │       ├── lab/              # Lab environment certs
    │       ├── stg/              # Staging environment certs
    │       └── prd/              # Production environment certs
    │
    └── collections/              # Ansible Galaxy collections (installed)
        └── ansible_collections/
            └── axonops/
                └── axonops/      # AxonOps Ansible collection

Key Files to Customize:

Infrastructure:
- terraform/terraform.tfvars - Hetzner Cloud configuration
- terraform/*.tfvars - Per-environment configs (lab, stg, prd)
Cassandra Configuration:
- ansible/group_vars/all/cassandra.yml - Global defaults
- ansible/group_vars/<env>/cassandra.yml - Environment overrides
AxonOps Configuration:
- ansible/group_vars/all/axonops.yml - Global defaults
- ansible/group_vars/<env>/axonops.yml - Environment settings
- ansible/group_vars/<env>/vault.yml - Encrypted credentials
Monitoring Configuration:
- ansible/alerts-config/<org>/alert_endpoints.yml - Alert integrations
- ansible/alerts-config/<org>/<cluster>/backups.yml - Backup schedules
- ansible/alerts-config/<org>/<cluster>/alert_routes.yml - Alert routing

Terraform Configuration

Infrastructure Components

The Terraform configuration creates:

Resource	Count	Purpose
Cassandra Nodes	12 (configurable)	Multi-DC cluster
Bastion Host	1	Secure access point
Private Network	1	Inter-node communication (10.18.0.0/16)
Placement Groups	6	Physical host diversity (1 per DC per rack)
Firewalls	2	Security rules (bastion + cassandra)
SSH Key	1	Auto-generated or existing

Customizing Infrastructure

Edit terraform/terraform.tfvars:

# Environment and location
environment = "lab"               # Used in resource naming
location    = "sin"               # Singapore (nbg1, fsn1, hel1, ash, hil)

# Instance types
server_type        = "cpx31"      # 4 vCPU, 8GB RAM per Cassandra node
bastion_server_type = "cpx11"     # 2 vCPU, 2GB RAM for bastion

# Storage
disk_size = 40                    # Data volume size in GB per Cassandra node

# Operating System
image = "ubuntu-24.04"            # OS image (ubuntu-24.04, ubuntu-22.04, etc.)

# Security - Bastion Access
allowed_cidrs = ["YOUR_IP/32"]    # IPs allowed to access bastion (SSH, HTTPS) and non-SQL port

# Security - Cassandra Access
allowed_cidrs_cassandra = ["0.0.0.0/0"]  # IPs allowed CQL/JMX access to Cassandra nodes

# SSH keys
ssh_keys = []                     # Empty = auto-generate, or ["key-name"]

# Object Storage (optional - for backups)
object_storage_region = "fsn1"
# object_storage_access_key = "set via env var"
# object_storage_secret_key = "set via env var"

Terraform Commands

The project includes a comprehensive Makefile for simplified Terraform operations. All Terraform targets are prefixed with tf-.

⚠️ STATE BACKEND WARNING: This setup uses local state files suitable only for lab environments. For staging/production, configure a remote backend (S3, Consul, Terraform Cloud) for state locking and team collaboration.

Quick Start:

cd terraform

# See all available commands
make tf-help

# Initialize Terraform
make tf-init

# Plan changes for lab environment (default)
make tf-plan

# Apply changes
make tf-apply

# Plan/apply for different environments
make tf-plan ENVIRONMENT=stg
make tf-apply ENVIRONMENT=prd

Common Makefile Commands:

Command	Description
`make tf-help`	Show all available commands
`make tf-init`	Initialize Terraform (download providers)
`make tf-plan`	Show execution plan
`make tf-apply`	Apply infrastructure changes
`make tf-destroy`	Destroy infrastructure
`make tf-output`	Show Terraform outputs
`make tf-console`	Open Terraform console
`make tf-validate`	Validate configuration
`make tf-fmt`	Format Terraform files

Environment Management:

# Use different environment configurations
make tf-plan ENVIRONMENT=lab    # Uses lab.terraform.tfvars (default)
make tf-plan ENVIRONMENT=stg    # Uses stg.terraform.tfvars
make tf-apply ENVIRONMENT=prd   # Uses prd.terraform.tfvars

Quick Deployment:

These are shortcuts equivalent to running all the terraform commands of a specific environment.

make tf-deploy-lab               # Full workflow: init → plan → apply → save inventory
make tf-deploy-stg               # Deploy staging
make tf-deploy-prd               # Deploy production

State Management:

make tf-state-list                        # List all resources in state
make tf-state-show RESOURCE=<name>        # Show specific resource details
make tf-refresh                           # Refresh state from real infrastructure

Additional Commands:

make tf-graph                    # Generate dependency graph (requires graphviz)
make tf-version                  # Show Terraform version
make tf-clean                    # Remove .terraform cache

Note: All commands use the Makefile which automatically handles environment-specific configuration files. The Makefile includes safety checks for required environment variables and configuration files.

Network Configuration

🔐 SECURITY NOTE - Two Firewall Variables: This project uses two separate firewall variables for granular access control:

allowed_cidrs - Controls access to bastion host only (SSH, HTTPS/Wetty)

allowed_cidrs_cassandra - Controls CQL (9042) and JMX access to Cassandra nodes

This separation allows you to restrict bastion access to your office IP while allowing application servers broader access to Cassandra.

Firewall Rules:

Bastion:

Port 22 (SSH) ← from allowed_cidrs
Port 443 (HTTPS/Wetty) ← from allowed_cidrs
Port 51920 (UDP/WireGuard) ← from all (for VPN access)

Cassandra Nodes:

Port 22 (SSH) ← from bastion + allowed_cidrs
Port 443 (HTTPS) ← from allowed_cidrs
Port 9042 (CQL) ← from allowed_cidrs_cassandra + private network
Ports 7000, 7001 (Gossip) ← from other Cassandra node IPs
All ports ← from private network (10.18.0.0/16)

Ansible Configuration

Available Make Commands

Run from the ansible/ directory:

Command	Playbook	Description
`make prep`	-	Install Ansible Galaxy collections
`make common`	common.yml	OS hardening, base packages, NTP, web terminal
`make cassandra`	cassandra.yml	Install Java, Cassandra 5.0.5, AxonOps agent
`make alerts`	alerts.yml	Configure monitoring, alerts, backups
`make rolling-restart`	rolling-restart.yml	Safe sequential cluster restart
`make wipe`	wipe.yml	Stop services and wipe data directories

Environment variable:

make cassandra ENVIRONMENT=lab    # Default
make cassandra ENVIRONMENT=prod   # For production

What Gets Installed

common.yml:

OS security hardening (devsec.hardening.os_hardening)
System packages: curl, jq, unzip, nginx, chrony
Chrony NTP for time synchronization
Wetty web terminal with HTTPS
CQLAI on bastion host only
Hosts file configuration for all nodes

cassandra.yml:

Java (from axonops.axonops.java role)
Apache Cassandra 5.0.5 (tarball installation)
AxonOps agent 2.0.9
AxonOps Java agent 1.0.10 for Cassandra 5.0
SSL/TLS keystores (if enabled)
Cassandra configuration:
- PasswordAuthenticator + CassandraAuthorizer
- Audit logging (DDL, DCL, AUTH, ERROR - excludes SELECT/INSERT/UPDATE/DELETE)
- GossipingPropertyFileSnitch
- Multi-DC seed configuration
- Data directory: /data/cassandra
cqlshrc configuration with SSL support
Service check scripts deployment
Wetty web terminal with nginx reverse proxy

alerts.yml:

AxonOps alert endpoints (Slack, PagerDuty, email)
Metric alert rules (CPU, disk, Cassandra metrics)
Log alert rules
Alert routing configuration
Backup schedules
Service checks (node down, schema disagreements, keyspace strategy)
Commitlog archiving

Cassandra Configuration

Global settings (group_vars/all/cassandra.yml):

cassandra_version: 5.0.5
cassandra_install_format: tar
cassandra_install_dir: /opt/cassandra
cassandra_endpoint_snitch: GossipingPropertyFileSnitch

# Data directories
cassandra_data_root: /data/cassandra
cassandra_data_directory: /data/cassandra/data
cassandra_commitlog_directory: /data/cassandra/commitlog
cassandra_log_dir: /var/log/cassandra

# Security
cassandra_authenticator: PasswordAuthenticator
cassandra_authorizer: CassandraAuthorizer
cassandra_auth_write_consistency_level: EACH_QUORUM

# Audit logging
cassandra_audit_log_enabled: true
# Logs: DDL, DCL, AUTH, ERROR (excludes SELECT, INSERT, UPDATE, DELETE)

# Performance
cassandra_concurrent_reads: 32
cassandra_concurrent_writes: 32
cassandra_concurrent_counter_writes: 32

# JMX authentication
cassandra_jmx_user: "jmxuser"
cassandra_jmx_password: "{{ vault_cassandra_jmx_password }}"

# Network
cassandra_listen_address: "{{ ansible_enp7s0.ipv4.address }}"
cassandra_broadcast_rpc_address: "{{ ansible_eth0.ipv4.address }}"
cassandra_rpc_address: 0.0.0.0

🌐 IMPORTANT - Network Configuration: Understanding the dual-network setup is critical for proper cluster operation. This environment uses two separate networks with different purposes:

Network Architecture:

Network	CIDR	Interface	Purpose	Used For
Private	`10.18.0.0/16`	`enp7s0`	Inter-node communication	Gossip, replication, internal traffic
Public	Dynamic	`eth0`	External access	Client connections, SSH, monitoring

How Cassandra Uses Each Network:

cassandra_listen_address → {{ ansible_enp7s0.ipv4.address }} (Private network)
- Gossip protocol communication between Cassandra nodes
- Data replication and streaming between nodes
- Lower latency, higher bandwidth
- Example: 10.18.1.10
cassandra_broadcast_rpc_address → {{ ansible_eth0.ipv4.address }} (Public network)
- CQL client connections from external applications
- AxonOps monitoring connections
- Administrative access
- Example: 95.217.123.45
cassandra_rpc_address → 0.0.0.0
- Binds CQL port 9042 to all interfaces
- Allows connections from both networks

Automatic Configuration via Ansible Facts:

Ansible automatically detects and configures the correct IP addresses for each node using network interface facts:

ansible_enp7s0.ipv4.address - Auto-detected private IP
ansible_eth0.ipv4.address - Auto-detected public IP

This ensures consistent configuration across all nodes without manual IP management.

💡 Tip: You can verify network configuration on any node with:

ip addr show enp7s0  # Private network (10.18.x.x)
ip addr show eth0    # Public network
nodetool gossipinfo  # Shows which IPs nodes use for gossip

Environment overrides (group_vars/lab/cassandra.yml):

📁 ANSIBLE ORGANIZATION PATTERN: Ansible variables follow a hierarchical override pattern:

group_vars/all/ - Contains settings common to all environments (lab, stg, prd)

group_vars/<env>/ - Contains environment-specific overrides for that environment

This pattern allows you to define defaults once in all/ and override only what's different per environment. For example, heap size, performance tuning, and cluster names are typically environment-specific, while default ports and paths remain the same.

# Auto-sizing heap (50% of RAM, max 40GB)
cassandra_max_heap_size: "{% if (ansible_memtotal_mb * 0.5 / 1024) | round | int > 40 %}40{% else %}{{ (ansible_memtotal_mb * 0.5 / 1024) | round | int }}{% endif %}G"

cassandra_concurrent_compactors: "4"
cassandra_compaction_throughput: "64MiB/s"
cassandra_counter_cache_save_period: "7200s"
cassandra_counter_write_request_timeout: "5000s"

Inventory variables (from Terraform):

[lab]
<cassandra-server-ip> cassandra_rack=rack1 cassandra_dc=dc1 ansible_hostname=cassandra-node-1
...

[all:vars]
cassandra_seeds=10.18.1.x,10.18.1.y,10.18.1.z,10.18.1.w  # 4 seeds (2 per DC)

AxonOps Configuration

Global settings (group_vars/all/axonops.yml):

NOTE: The default configuration is set for AxonOps SaaS. For on-premises configuation please refer to the AxonOps documention on how configure the corect host and port.

axon_agent_version: "2.0.9"
axon_java_agent_version: "1.0.10"
axon_java_agent: "axon-cassandra5.0-agent-jdk17"

axon_agent_hosts: "agents.axonops.cloud"
axon_agent_port: 443

axon_agent_disable_command_exec: true  # Disable remote command execution

cqlai_host: "localhost"
cqlai_port: 9042

Environment secrets (group_vars/lab/vault.yml):

---
vault_axon_agent_customer_name: "your-org-name"
vault_axon_agent_key: "your-agent-key-from-console"

Environment config (group_vars/lab/axonops.yml):

axon_agent_customer_name: "{{ vault_axon_agent_customer_name }}"
axon_agent_key: "{{ vault_axon_agent_key }}"
axon_agent_ntp_server: "time.cloudflare.com"

Managing Secrets with Ansible Vault

All sensitive data is encrypted using Ansible Vault:

# Create vault password file
export ENVIRONMENT=lab
export ANSIBLE_VAULT_PASSWORD_FILE=~/.ansible_vault_pass_${ENVIRONMENT}
echo "my-secure-password" > ~/.ansible_vault_pass_${ENVIRONMENT}
chmod 600 ~/.ansible_vault_pass_${ENVIRONMENT}

# Edit vault file
ansible-vault edit group_vars/lab/vault.yml

# View vault contents
ansible-vault view group_vars/lab/vault.yml

# Encrypt existing file
ansible-vault encrypt group_vars/lab/vault.yml

# Decrypt file
ansible-vault decrypt group_vars/lab/vault.yml

# Change vault password
ansible-vault rekey group_vars/lab/vault.yml

AxonOps Monitoring Configuration

Monitoring is configured via YAML files in alerts-config/<org-name>/:

Organization Level:

alert_endpoints.yml - Slack, PagerDuty, email integrations
metric_alert_rules.yml - Default metric alerts for all clusters
log_alert_rules.yml - Default log alerts for all clusters

Cluster Level (alerts-config/<org-name>/<cluster-name>/):

alert_routes.yml - Route specific alerts to endpoints
backups.yml - Backup schedules and retention
service_checks.yml - Custom health check scripts
commitlog_archive.yml - Commitlog archiving configuration
dashboards.yml - Custom dashboard definitions
metric_alert_rules.yml - Cluster-specific metric overrides
log_alert_rules.yml - Cluster-specific log overrides

Example structure:

alerts-config/
└── training/                          # Your organization name
    ├── alert_endpoints.yml
    ├── metric_alert_rules.yml
    ├── log_alert_rules.yml
    └── lab/                           # Cluster name
        ├── alert_routes.yml
        ├── backups.yml
        ├── service_checks.yml
        ├── commitlog_archive.yml
        ├── dashboards.yml
        ├── metric_alert_rules.yml
        └── log_alert_rules.yml

Apply monitoring configuration:

cd ansible
make alerts ENVIRONMENT=lab

Full documentation on alerts can be found here

Complete Deployment Workflow

Phase 1: Infrastructure Setup with Terraform

# 1. Export Hetzner Cloud token
export HCLOUD_TOKEN="your-hetzner-token"

# 2. Navigate to Terraform directory
cd terraform

# 3. Create configuration file
cp terraform.tfvars.example terraform.tfvars
vim terraform.tfvars  # Edit with your preferences

# 4. Initialize Terraform
make tf-init

# 5. Deploy infrastructure
make tf-apply

# 6. Save inventory to Ansible directory
make tf-inventory-save

# 7. View outputs (bastion IP, node IPs, etc.)
make tf-output

Phase 2: Prepare Ansible Configuration

cd ../ansible

# 1. Set up vault password
export ENVIRONMENT=lab
export ANSIBLE_VAULT_PASSWORD_FILE=~/.ansible_vault_pass_${ENVIRONMENT}

echo "your-vault-password" > ~/.ansible_vault_pass_${ENVIRONMENT}
chmod 600 ~/.ansible_vault_pass_${ENVIRONMENT}

# 2. Install Ansible dependencies
make prep

# 3. Configure AxonOps credentials
ansible-vault edit group_vars/lab/vault.yml
# Add:
#   vault_axon_agent_customer_name: "your-org"
#   vault_axon_agent_key: "your-key"

# 4. (Optional) Customize Cassandra settings
vim group_vars/lab/cassandra.yml

# 5. Set environment for all commands
export ENVIRONMENT=lab

Phase 3: Base System Configuration

# Deploy OS hardening, NTP, base packages, web terminal
make common ENVIRONMENT=lab

# This installs:
# - OS security hardening
# - chrony (NTP)
# - nginx, curl, jq, unzip
# - Wetty web terminal at https://<bastion-ip>/wetty
# - CQLAI on bastion
# - Hosts file configuration

Phase 4: Cassandra Deployment

# Deploy Cassandra cluster and AxonOps agent
make cassandra ENVIRONMENT=lab

# This installs:
# - Java
# - Apache Cassandra 5.0.5
# - AxonOps agent 2.0.9
# - Configures SSL, authentication, audit logging
# - Sets up cqlshrc and service checks

Phase 5: Monitoring Setup

The credentials can be configured in two different ways. The prefered option is to use Ansible Vault with

vault_axon_agent_customer_name: your-org
vault_axon_token: token

or with env variables:

# 1. Set AxonOps API credentials
export AXONOPS_ORG="your-org-name"
export AXONOPS_TOKEN="your-api-token"

# 2. Create monitoring configuration (if not using existing)
mkdir -p alerts-config/your-org-name/lab
# Copy examples from alerts-config/training/

# 3. Apply monitoring
make alerts ENVIRONMENT=lab

Phase 6: Verification

# 1. Access bastion
ssh root@<bastion-ip>

# 2. Check cluster status from bastion
ssh root@10.18.1.x  # Any Cassandra node private IP
nodetool status

# Expected output:
# Datacenter: dc1
# Status=Up/Down
# |/ State=Normal/Leaving/Joining/Moving
# --  Address      Load       Tokens  Owns    Host ID   Rack
# UN  10.18.1.x    ...        256     ...     ...       rack1
# UN  10.18.1.y    ...        256     ...     ...       rack1
# (6 nodes in dc1, 6 in dc2)

# 3. Test CQL access
cqlsh
cqlai
# Connected to lab at 10.18.1.x:9042

# 4. Check AxonOps agent
systemctl status axon-agent

# 5. View in AxonOps Console
# Visit: https://console.axonops.cloud/

Advanced Operations

Configuration Updates

Update Cassandra configuration without reinstalling:

cd ansible

# 1. Edit configuration
vim group_vars/lab/cassandra.yml

# 2. Apply only config changes (no restart)
make cassandra ENVIRONMENT=lab EXTRA="--tags config"

# 3. Perform rolling restart
make rolling-restart ENVIRONMENT=lab

Rolling Restart

Safe, sequential restart with health checks:

cd ansible
make rolling-restart ENVIRONMENT=lab

The playbook:

Restarts nodes one at a time (serial: 1)
Restarts both Cassandra and axon-agent services
Waits for Cassandra to bind to port 9042
Proceeds to next node only after current is healthy

Scaling the Cluster

To add more nodes (e.g., from 12 to 15):

# 1. Update Terraform node count
cd terraform
vim main.tf
# Change: resource "hcloud_server" "cassandra" { count = 15 }

# 2. Update placement group assignments and labels
# Adjust the placement_group_id and labels logic for new nodes
# You may need additional placement groups for dc3 or more racks

# 3. Apply infrastructure changes
make tf-apply

# 4. Deploy Cassandra to all nodes (including new ones)
cd ../ansible
make cassandra ENVIRONMENT=lab

# 6. Verify cluster
# SSH to any node and run: nodetool status

SSL/TLS Configuration

Option 1: Auto-generated certificates (lab environments):

# In group_vars/lab/cassandra.yml
cassandra_ssl_create: true

# Deploy
make cassandra ENVIRONMENT=lab EXTRA="--tags ssl,keystore"
make rolling-restart ENVIRONMENT=lab

Option 2: Custom certificates (production):

# 1. Place certificates in files/ssl/lab/
mkdir -p files/ssl/lab
# Copy: keystore.jks, truststore.jks, etc.

# 2. Configure in group_vars/lab/ssl.yml
vim group_vars/lab/ssl.yml

# 3. Store passwords in vault
ansible-vault edit group_vars/lab/ssl_vault.yml
# Add: vault_ssl_keystore_password, vault_ssl_truststore_password

# 4. Deploy SSL configuration
make cassandra ENVIRONMENT=lab EXTRA="--tags ssl,config"
make rolling-restart ENVIRONMENT=lab

AxonOps Backup Configuration

Edit alerts-config/<org>/<cluster>/backups.yml:

axonops_backups:
  - name: "hourly-incremental"
    schedule: "0 * * * *"           # Every hour
    type: "incremental"
    destination: "s3"
    s3_bucket: "cassandra-backups"
    s3_prefix: "lab/incremental"
    retention_days: 7

  - name: "daily-full"
    schedule: "0 3 * * *"           # 3 AM daily
    type: "full"
    destination: "s3"
    s3_bucket: "cassandra-backups"
    s3_prefix: "lab/full"
    retention_days: 30

  - name: "weekly-snapshot"
    schedule: "0 4 * * 0"           # Sunday 4 AM
    type: "snapshot"
    destination: "s3"
    s3_bucket: "cassandra-backups"
    s3_prefix: "lab/snapshots"
    retention_days: 90

Apply:

make backups ENVIRONMENT=lab

Ad-Hoc Commands

cd ansible

# Check cluster status on all nodes
pipenv run ansible -i inventories/lab/hosts.ini cassandra \
  -m shell -a "nodetool status"

# Check AxonOps agent status
pipenv run ansible -i inventories/lab/hosts.ini cassandra \
  -m shell -a "systemctl status axon-agent"

# Restart a specific node
pipenv run ansible -i inventories/lab/hosts.ini cassandra \
  --limit "5.223.73.105" \
  -m service -a "name=cassandra state=restarted"

# Collect logs from all nodes
pipenv run ansible -i inventories/lab/hosts.ini cassandra \
  -m fetch -a "src=/var/log/cassandra/system.log dest=/tmp/logs/"

# Check disk space
pipenv run ansible -i inventories/lab/hosts.ini cassandra \
  -m shell -a "df -h /data/cassandra"

# Check heap usage
pipenv run ansible -i inventories/lab/hosts.ini cassandra \
  -m shell -a "nodetool info | grep Heap"

# Ping all hosts
pipenv run ansible -i inventories/lab/hosts.ini all -m ping

# Stop/Start nginx and wetty on all nodes
make stop-nginx ENVIRONMENT=lab
make start-nginx ENVIRONMENT=lab

Wipe Data (⚠️ Destructive)

Completely remove all Cassandra data:

cd ansible
make wipe ENVIRONMENT=lab

# This will:
# 1. Stop axon-agent
# 2. Stop cassandra
# 3. Delete /data/cassandra/*

After wiping, redeploy:

make cassandra ENVIRONMENT=lab

Web Terminal Access (LAB Environment ONLY!)

Each node runs Wetty for browser-based SSH access:

Access:

URL: https://<node-public-ip>/wetty
Username: wetty (configurable)
Password: (must be set in vault)

Features:

Browser-based terminal
No SSH client required
Self-signed SSL certificate
Nginx reverse proxy on port 443
HTTP basic authentication

Configuration:

Wetty is configured in two places:

Global defaults (ansible/group_vars/all/wetty.yml):

wetty_use_nginx: true
wetty_nginx_port: 443
wetty_server_name: "{{ ansible_fqdn }}"

# SSL settings
wetty_use_ssl: true
wetty_generate_self_signed_cert: true
wetty_ssl_cert_path: "/etc/ssl/certs/wetty.pem"
wetty_ssl_key_path: "/etc/ssl/private/wetty.key"

# HTTP basic auth
wetty_http_username: wetty
wetty_http_password: "{{ vault_wetty_http_password }}"

Environment-specific password (stored in vault):

# Edit vault file for your environment
ansible-vault edit group_vars/lab/vault.yml

# Add the Wetty password:
vault_wetty_http_password: "your-secure-password-here"

To customize:

Change username: Edit wetty_http_username in group_vars/all/wetty.yml
Change password: Edit vault_wetty_http_password in group_vars/<env>/vault.yml
Disable SSL: Set wetty_use_ssl: false in environment-specific config
Change port: Set wetty_nginx_port to different port

Troubleshooting

Terraform Issues

Problem: Can't SSH to instances

# Verify your IP is in allowed_cidrs
make tf-output

# Test connection
ssh root@<bastion-ip>

Problem: Placement group errors

# Normal for spread placement groups - Terraform will retry
# If persistent, reduce node count or change placement strategy

Problem: Inventory not generated

# Manually trigger
cd terraform
make tf-inventory-save

Ansible Issues

Problem: Vault password not found

# Ensure vault password file exists and is set
export ENVIRONMENT=lab
export ANSIBLE_VAULT_PASSWORD_FILE=~/.ansible_vault_pass_${ENVIRONMENT}
cat ~/.ansible_vault_pass_${ENVIRONMENT}  # Should contain your password

# Test vault access
ansible-vault view group_vars/lab/vault.yml

Problem: "Failed to connect to host"

# Check SSH connectivity
ssh root@<node-ip>

# Verify inventory
cat inventories/lab/hosts.ini

# Check firewall rules (ensure your IP is in allowed_cidrs)
cd ../terraform
make tf-output

Problem: AxonOps agent not connecting

# SSH to node and check logs
ssh root@<node-ip>
journalctl -u axon-agent -n 100 -f

# Common causes:
# 1. Wrong agent key (check vault.yml)
# 2. Wrong organization name
# 3. Firewall blocking agents.axonops.cloud:443

# Verify configuration
cat /etc/axonops/axon-agent.yml

# Test connectivity
curl -v https://agents.axonops.cloud:443

Cassandra Issues

Problem: Nodes showing as DN (Down)

# Check Cassandra logs
tail -100 /var/log/cassandra/system.log

# Check service status
systemctl status cassandra

# Common causes:
# 1. Insufficient heap (check cassandra_max_heap_size)
# 2. Network connectivity issues (check gossip ports)
# 3. Seed node misconfiguration (verify cassandra_seeds)
# 4. Time sync issues (check chrony status)

# Check heap settings
grep -i heap /opt/cassandra/conf/jvm*.options

# Verify seed nodes
grep seeds /opt/cassandra/conf/cassandra.yaml

Problem: Cluster not forming

# Verify datacenter/rack in cassandra-rackdc.properties
cat /opt/cassandra/conf/cassandra-rackdc.properties

# Should show:
# dc=dc1  (or dc2)
# rack=rack1  (or rack2, rack3)

# Check gossip info
nodetool gossipinfo

# Verify network connectivity between nodes
nodetool describecluster

Problem: Authentication errors

# Default credentials:
# Username: cassandra
# Password: cassandra

# Connect with cqlsh
cqlsh --ssl -u cassandra -p cassandra

# Change default password:
ALTER ROLE cassandra WITH PASSWORD = 'new-secure-password';

Problem: Performance issues

# Check heap usage
nodetool info | grep Heap

# Check GC stats
nodetool gcstats

# Check compaction stats
nodetool compactionstats

# Check table statistics
nodetool tablestats <keyspace>.<table>

# Review AxonOps Console for detailed metrics

Network Issues

Problem: Can't connect to CQL port 9042

# Verify firewall allows your IP
cd terraform
make tf-output

# Test connectivity
nc -zv <node-ip> 9042

# Check Cassandra is listening
ssh root@<node-ip> "netstat -tuln | grep 9042"

Problem: Inter-node communication failing

# Check private network assignment
ssh root@<node-ip> "ip addr show enp7s0"
# Should have 10.18.1.x address

# Test gossip connectivity
ssh root@<node-ip> "nodetool status"

# Check firewall rules allow inter-node traffic
# Ports 7000, 7001, 9042 should be open between Cassandra nodes

Multi-Environment Setup

This project supports multiple isolated environments (lab, staging, production) running simultaneously or separately. Each environment has its own:

Terraform state and infrastructure
Ansible inventory and configuration
AxonOps cluster monitoring
Network isolation

⚠️ STATE BACKEND WARNING: For production and staging environments, you MUST configure a remote state backend instead of using local state files. Remote backends provide state locking, versioning, and team collaboration capabilities.

Environment Naming Convention

We recommend using short environment codes:

lab - Development/testing environment (default) - local state OK
stg - Staging environment for pre-production testing - requires remote state
prd - Production environment - requires remote state

Creating a Staging Environment

# 1. Create staging infrastructure with Terraform
cd terraform

# Create staging configuration
cat > stg.tfvars <<EOF
environment = "stg"
location    = "fsn1"              # Falkenstein (or your preferred location)
server_type = "cpx31"             # 4 vCPU, 8GB RAM
bastion_server_type = "cpx11"
allowed_cidrs = ["YOUR_IP/32"]
ssh_keys = []
EOF

# Deploy staging infrastructure
make tf-apply ENVIRONMENT=stg

# 2. Create staging Ansible configuration
cd ../ansible

# Create staging group_vars
mkdir -p group_vars/stg
cp -r group_vars/lab/* group_vars/stg/

# Update staging-specific settings
vim group_vars/stg/cassandra.yml
# Adjust: cassandra_cluster_name: "stg"
#         heap sizes, performance tuning, etc.

vim group_vars/stg/axonops.yml
# Keep: axon_agent_customer_name and axon_agent_key reference vault

# Create staging vault with credentials
ansible-vault create group_vars/stg/vault.yml
# Add:
#   vault_axon_agent_customer_name: "your-org"
#   vault_axon_agent_key: "your-agent-key"

# 3. Create staging monitoring configuration
mkdir -p alerts-config/<your-org>/stg
cp -r alerts-config/<your-org>/lab/* alerts-config/<your-org>/stg/

# Customize staging alerts
vim alerts-config/<your-org>/stg/alert_routes.yml
vim alerts-config/<your-org>/stg/backups.yml

# 4. Deploy staging cluster
make common ENVIRONMENT=stg
make cassandra ENVIRONMENT=stg
make alerts ENVIRONMENT=stg

# 5. Verify staging cluster
ssh root@<stg-bastion-ip>
ssh root@<stg-node-private-ip>
nodetool status

Creating a Production Environment

⚠️ CRITICAL: Before deploying production, configure a remote state backend in your Terraform configuration to prevent state conflicts and data loss.

# 1. Create production infrastructure with Terraform
cd terraform

# Create production configuration with larger instances
cat > prd.tfvars <<EOF
environment = "prd"
location    = "hel1"              # Helsinki (or your preferred location)
server_type = "cpx51"             # 16 vCPU, 32GB RAM for production
bastion_server_type = "cpx21"     # Larger bastion for production
allowed_cidrs = ["VPN_IP/32", "OFFICE_IP/32"]  # Restrict to known IPs only
ssh_keys = ["prod-ssh-key"]       # Use existing SSH key for security
EOF

# Deploy production infrastructure
make tf-apply ENVIRONMENT=prd

# Save inventory to Ansible directory
make tf-inventory-save ENVIRONMENT=prd

# 2. Create production Ansible configuration
cd ../ansible

# Create production group_vars
mkdir -p group_vars/prd

# Copy base configuration
cp -r group_vars/lab/* group_vars/prd/

# Configure production Cassandra settings
cat > group_vars/prd/cassandra.yml <<EOF
---
# Production-specific overrides

# Larger heap for production (adjust based on your instance size)
cassandra_max_heap_size: "16G"
cassandra_heap_newsize: "4G"

# Higher concurrency for production workload
cassandra_concurrent_compactors: "8"
cassandra_compaction_throughput: "128MiB/s"
cassandra_concurrent_reads: 64
cassandra_concurrent_writes: 64

# Production cache sizes
cassandra_counter_cache_save_period: "7200s"
cassandra_counter_write_request_timeout: "10000s"

# Cluster name
cassandra_cluster_name: "prd"
EOF

# Configure production AxonOps settings
vim group_vars/prd/axonops.yml

# Create production vault (IMPORTANT: Use production credentials!)
ansible-vault create group_vars/prd/vault.yml
# Add:
#   vault_axon_agent_customer_name: "your-org"
#   vault_axon_agent_key: "your-production-agent-key"

# (Optional) Configure SSL for production
vim group_vars/prd/ssl.yml
ansible-vault create group_vars/prd/ssl_vault.yml

# 3. Create production monitoring configuration
mkdir -p alerts-config/<your-org>/prd
cp -r alerts-config/<your-org>/lab/* alerts-config/<your-org>/prd/

# Configure production-specific monitoring
vim alerts-config/<your-org>/prd/alert_routes.yml
# Route critical alerts to PagerDuty for production

vim alerts-config/<your-org>/prd/backups.yml
# More frequent backups and longer retention for production:
# Hourly incrementals, daily fulls, weekly snapshots

vim alerts-config/<your-org>/prd/service_checks.yml
# Stricter thresholds for production

# 4. Deploy production cluster
make common ENVIRONMENT=prd
make cassandra ENVIRONMENT=prd
make alerts ENVIRONMENT=prd

# 5. Verify production cluster
ssh root@<prd-bastion-ip>
ssh root@<prd-node-private-ip>
nodetool status

# 6. Check AxonOps Console
# Visit: https://console.axonops.cloud/
# Verify you see separate clusters: "lab", "stg", "prd"

Environment Comparison

Aspect	Lab	Staging	Production
Purpose	Development/Testing	Pre-production validation	Live production
Instance Size	cpx31 (4vCPU, 8GB)	cpx31 (4vCPU, 8GB)	cpx51 (16vCPU, 32GB)
Node Count	12	12	12-15
Heap Size	Auto (4-8GB)	Auto (4-8GB)	16GB+
SSL/TLS	Optional	Recommended	Required
Access Control	Open (for testing)	Restricted	Highly restricted
Backup Retention	7 days	14 days	30-90 days
Alert Routing	Email	Slack	PagerDuty + Slack
Cost (monthly)	~€155	~€155	~€310

Managing Multiple Environments

Work with specific Terraform environment:

cd terraform

# Work with lab environment (default, local state)
make tf-plan ENVIRONMENT=lab
make tf-apply ENVIRONMENT=lab

# Work with staging environment (should use remote state)
make tf-plan ENVIRONMENT=stg
make tf-apply ENVIRONMENT=stg

# Work with production environment (should use remote state)
make tf-plan ENVIRONMENT=prd
make tf-apply ENVIRONMENT=prd

Deploy to specific environment with Ansible:

cd ansible

# Deploy to staging
make cassandra ENVIRONMENT=stg

# Deploy to production
make cassandra ENVIRONMENT=prd

# Rolling restart staging
make rolling-restart ENVIRONMENT=stg

View environment in AxonOps Console:

Each environment appears as a separate cluster in the AxonOps Console:

Cluster name: lab, stg, or prd
Organization: Same organization for all environments
Monitoring: Isolated metrics and alerts per cluster

Best Practices for Multiple Environments

Terraform State Management
- Lab: Local state files are acceptable for development/testing
- Staging/Production: MUST use remote state backend (S3, Azure Storage, Terraform Cloud, etc.)
- Configure state locking to prevent concurrent modifications
- Enable state versioning for rollback capability
- Never commit state files to version control
Credentials Management
- Use separate vault files per environment
- Use different SSH keys for production
- Rotate production credentials regularly
Network Isolation
- Deploy environments in different regions if possible
- Use separate private networks per environment
- Restrict production access to VPN/office IPs only
Progressive Deployment
- Test changes in lab first
- Promote to stg for validation
- Deploy to prd only after staging validation
Monitoring Separation
- Configure different alert routes per environment
- Use PagerDuty for production, Slack for staging/lab
- Set stricter thresholds for production alerts
Backup Strategy
- Lab: Minimal backups (7 days)
- Staging: Regular backups (14 days)
- Production: Comprehensive backups (30-90 days)

Destroying an Environment

# Destroy lab environment
cd terraform
make tf-destroy ENVIRONMENT=lab

cd ../ansible
rm -rf group_vars/lab
rm -rf inventories/lab
rm -rf alerts-config/<org>/lab

# Destroy staging environment
cd terraform
make tf-destroy ENVIRONMENT=stg

cd ../ansible
rm -rf group_vars/stg
rm -rf inventories/stg
rm -rf alerts-config/<org>/stg

Performance Tuning

For SSD-backed nodes:

Edit group_vars/<env>/cassandra.yml:

cassandra_concurrent_compactors: "4"
cassandra_compaction_throughput: "64MiB/s"
cassandra_concurrent_reads: 32
cassandra_concurrent_writes: 32

For high-memory nodes:

# Auto-calculated: 50% of RAM, max 40GB
cassandra_max_heap_size: "{% if (ansible_memtotal_mb * 0.5 / 1024) | round | int > 40 %}40{% else %}{{ (ansible_memtotal_mb * 0.5 / 1024) | round | int }}{% endif %}G"

# Or set manually:
cassandra_max_heap_size: "16G"
cassandra_heap_newsize: "3200M"  # Usually 1/4 of heap

For write-heavy workloads:

cassandra_concurrent_writes: 64
cassandra_commitlog_total_space_in_mb: 8192
cassandra_memtable_flush_writers: 4

Additional Resources

AxonOps Documentation: docs.axonops.com
AxonOps Console: console.axonops.cloud
Ansible AxonOps Collection: galaxy.ansible.com/axonops/axonops

License

See LICENSE file.

📄 Legal Notices

This project may contain trademarks or logos for projects, products, or services. Any use of third-party trademarks or logos are subject to those third-party's policies.

AxonOps is a registered trademark of AxonOps Limited.
Apache, Apache Cassandra, Cassandra, Apache Spark, Spark, Apache TinkerPop, TinkerPop, Apache Kafka and Kafka are either registered trademarks or trademarks of the Apache Software Foundation or its subsidiaries in Canada, the United States and/or other countries.
DataStax is a registered trademark of DataStax, Inc. and its subsidiaries in the United States and/or other countries.

Name		Name	Last commit message	Last commit date
Latest commit History 7 Commits
ansible		ansible
exercises		exercises
terraform		terraform
workbench		workbench
.gitignore		.gitignore
.pre-commit-config.yaml		.pre-commit-config.yaml
.yamllint		.yamllint
LICENSE		LICENSE
README.md		README.md

License

axonops/ansible-cassandra-lab

Folders and files

Latest commit

History

Repository files navigation

AxonOps Apache Cassandra Lab

Apache Cassandra Lab Environment

Overview

Architecture

Current Default Topology (12 Nodes)

Prerequisites

Required Accounts & Credentials

Required Tools

Python Environment Management

Install Dependencies

Quick Start

1. Clone and Setup

2. Configure Environment Variables

3. Provision Infrastructure with Terraform

SSH Key Configuration

4. Configure Secrets with Ansible Vault

5. SSL/TLS Certificate Configuration

Option A: Auto-generated Certificates (Lab/Development Only)

Option B: Managed Certificates (Staging/Production - Recommended)

6. Deploy Cassandra Cluster

7. Access Your Cluster

8. Connect with AxonOps Workbench

Project Structure

Terraform Configuration

Infrastructure Components

Customizing Infrastructure

Terraform Commands

Network Configuration

Ansible Configuration

Available Make Commands

What Gets Installed

Cassandra Configuration

AxonOps Configuration

Managing Secrets with Ansible Vault

AxonOps Monitoring Configuration

Complete Deployment Workflow

Phase 1: Infrastructure Setup with Terraform

Phase 2: Prepare Ansible Configuration

Phase 3: Base System Configuration

Phase 4: Cassandra Deployment

Phase 5: Monitoring Setup

Phase 6: Verification

Advanced Operations

Configuration Updates

Rolling Restart

Scaling the Cluster

SSL/TLS Configuration

AxonOps Backup Configuration

Ad-Hoc Commands

Wipe Data (⚠️ Destructive)

Web Terminal Access (LAB Environment ONLY!)

Troubleshooting

Terraform Issues

Ansible Issues

Cassandra Issues

Network Issues

Multi-Environment Setup

Environment Naming Convention

Creating a Staging Environment

Creating a Production Environment

Environment Comparison

Managing Multiple Environments

Best Practices for Multiple Environments

Destroying an Environment

Performance Tuning

For SSD-backed nodes:

For high-memory nodes:

For write-heavy workloads:

Additional Resources

License

📄 Legal Notices

About

Resources

License

Packages
