AsmMos6502

AsmMos6502 is a lightweight and efficient C# library to assemble and disassemble 6502 assembly code. It provides a fluent API to create 6502 assembly code (e.g. a CPU powering the Commodore 64), and can be used to generate binary files or disassemble existing binaries into assembly code.

✨ Features

• Full support for all core 6502 instructions
• Unique strongly typed and fluent assembler API
• Support producing debug information (C# file and line numbers) for each instruction
• Easily disassemble instructions and operand.
• High performance / zero allocation library for disassembling / assembling instructions.
• Compatible with net8.0+ and NativeAOT.

📖 User Guide

Suppose that we want to write a simple program in C# to assemble and disassemble the equivalent of the following 6502 assembly code:

        .org $c000             ; Start address (for example, on C64 this is an available memory area)

        ; Initialization
START:  LDX #$00               ; X = 0, index into buffer
        LDY #$10               ; Y = 16, number of bytes to process

LOOP:   LDA $0200,X            ; Load byte at $0200 + X
        CMP #$FF               ; Check if byte is already 0xFF
        BEQ SKIP               ; If so, skip incrementing

        CLC                    ; Clear carry before addition
        ADC #$01               ; Add 1
        STA $0200,X            ; Store result back to memory

SKIP:   INX                    ; X = X + 1
        DEY                    ; Y = Y - 1
        BNE LOOP               ; Loop until Y == 0

        ; Call subroutine to flash border color
        JSR FLASH_BORDER

        ; Infinite loop
END:    JMP END

; ------------------------------
; Subroutine: FLASH_BORDER
; Cycles border color between 0–7
; (Useful on C64, otherwise dummy)
; ------------------------------
FLASH_BORDER:
        LDX #$00

FLASH_LOOP:
        STX $D020              ; C64 border color register
        INX
        CPX #$08
        BNE FLASH_LOOP

        RTS

The following C# assembly would assemble this code using the AsmMos6502 library:

using var asm = new Mos6502Assembler();

asm
    .Begin(0xc000)         // Start address (for example, on C64 this is an available memory area)
    .Label("START", out var startLabel)
    .LDX(0x00)             // X = 0, index into buffer
    .LDY(0x10)             // Y = 16, number of bytes to process

    .Label("LOOP", out var loopLabel)
    .LDA(0x0200, X) // Load byte at $0200 + X
    .CMP(0xFF)             // Check if byte is already 0xFF

    .LabelForward("SKIP", out var skipLabel)
    .BEQ(skipLabel)        // If so, skip incrementing
    .CLC()                 // Clear carry before addition
    .ADC(0x01)             // Add 1
    .STA(0x0200, X) // Store result back to memory

    .Label(skipLabel)      // X = X + 1
    .INX()
    .DEY()                 // Y = Y - 1
    .BNE(loopLabel)        // Loop until Y == 0

    // Call subroutine to flash border color
    .LabelForward("FLASH_BORDER", out var flashBorderLabel)
    .JSR(flashBorderLabel)

    // Infinite loop
    .Label("END", out var endLabel)
    .JMP(endLabel)

    // ------------------------------
    // Subroutine: FLASH_BORDER
    // Cycles border color between 0–7
    // (Useful on C64, otherwise dummy)
    // -----------------------------
    .Label(flashBorderLabel)
    .LDX(0x00)

    .Label("FLASH_LOOP", out var flashLoopLabel)
    .STX(0xD020) // C64 border color register
    .INX()
    .CPX(0x08)
    .BNE(flashLoopLabel)
    .RTS()

    .End();                 // Mark the end of the assembly (to resolve labels)

var buffer = asm.Buffer; // Get the assembled buffer

Disassembling the same code can be done using the Mos6502Disassembler class:

var dis = new Mos6502Disassembler(new Mos6502DisassemblerOptions()
{
    PrintLabelBeforeFirstInstruction = false,
    PrintAddress = true,
    PrintAssemblyBytes = true,
});

var asmText = dis.Disassemble(asm.Buffer);
Console.WriteLine(asmText);

Will generate the following disassembled code:

C000  A6 00      LDX $00
C002  A4 10      LDY $10

LL_02:
C004  BD 00 02   LDA $0200,X
C007  C5 FF      CMP $FF
C009  F0 06      BEQ LL_01

C00B  18         CLC
C00C  65 01      ADC $01
C00E  9D 00 02   STA $0200,X

LL_01:
C011  E8         INX
C012  88         DEY
C013  D0 EF      BNE LL_02

C015  20 1B C0   JSR LL_03

LL_04:
C018  4C 18 C0   JMP LL_04

LL_03:
C01B  A6 00      LDX $00

LL_05:
C01D  8E 20 D0   STX $D020
C020  E8         INX
C021  E4 08      CPX $08
C023  D0 F8      BNE LL_05

C025  60         RTS

For more details on how to use AsmMos6502, please visit the user guide.

🪪 License

This software is released under the BSD-2-Clause license.
